Wix Wl10255xp Engine Oil Filter

WIX WL10255XP Engine Oil Filter

WIX WL10255XP Engine Oil Filter

Engine Oil Filter

SPECIFICATIONS:

• Anti-Drain Back Valve: Yes
• Burst Pressure: 350 PSI
• Bypass Relief Valve Setting: 22
• Class: A
• Duty Type: LD
• Height: 4.474 in
• Inner Diameter Top: Closed
• Media Material: Synthetic
• OEM Interchange: UPG63R, WL10255, WL10255XP, WL610255, WL610255X, WPH500
• Outer Diameter Top: 2.921 in
• Style: Spin-On Lube Filter
• Thread Size: 22X1.5 MM in

This item may interchange to the following part numbers from other brands. This is provided for reference only and does not guarantee that the part your are buying is identical to the part numbers from the brands listed below. To confirm that this part fits your vehicle, enter your vehicles Year, Make, Model, Trim and Engine in the Compatibility Table.

• AC DELCO PF63
• AC DELCO PF63E
• AC DELCO PF63F
• AUTO EXTRA 618-10255
• CHAMP PH500XL
• DURAMAX DO500
• FACTORY MOTOR R0255
• FEDERATED UPG63R
• FVP EXTENDED LIFE R0255-XL
• FVP OIL FILTER R0255
• GENERAL MOTORS 89017525
• GENERAL MOTORS 12690385
• GENERAL MOTORS 12707246
• GENERAL MOTORS 19330000
• GENERAL MOTORS 19330001
• K&N HP2011
• LUBERFINER PH10063
• MICRO-GARD-WIX MGL10255
• NAPA GOLD 100255
• NAPA PLATINUM 4100255
• NAPA PROSELECT 2100255
• OREILLY PROTEC MP PTL10255MP
• PREMIUM GUARD UPG63R
• PRO-TEC PTL10255MP
• PRO-TEC 127
• PROTEC-NEW PXL10255
• PROTEC-NEW PXL10255MP
• PUREZONE 8-10255
• SERVICE CHAMP OF2500
• STP S45013

WIX XP Oil Filters provide robust engine protection when using synthetic motor oil for harsh driving conditions such as towing, extreme idle time, lower gear mountainous climbs, long periods at highway speeds. WIX XP filters are recommended for OEM oil and filter change intervals, typically 3,750 to 10,000 miles. This filter traps up to 100% more dirt and contaminants than WIX to resist premature plugging due to oil breakdown. Fully synthetic media withstands the harsh oil temperatures and conditions. A specifically formulated HNBR gasket provides an excellent seal during extreme cold engine starts and resist hardening under elevated oil temperatures. When applicable, WIX XP silicone antidrain back valve protects against dry starts past the traditional filter change interval. Oil Filter Laboratory Test Performance per ISO 454812 32 grams dirt (51515XP), 99% efficient at 35 microns (Based on 51515XP 51356XP, 57060XP)

Additional Specifications:

MediaType: Enhanced Cellulose

Class: D

Height (in): 4.776

Outer Diameter Top (in): 2.921

Duty Type: LD

Inner Diameter Top: Closed

ByPassValveSetting: 22

BetaRatio: 2/20=6/20

AntiDrainBackValve: Yes

Micron (Micro): 21.00

BurstPressure (PSI): 350

Location: MAIN

ThreadSize (in): 22X1.5 MM

Style: Spin-On Lube Filter

Fits the following vehicles: 2013-2019 Cadillac XTS, 2012 Chevrolet Captiva Sport, 2014-2018 Chevrolet Silverado 2500, 2015-2022 Chevrolet Tahoe, 2011-2016 Cadillac SRX, 2020-2022 Cadillac CT5, 2015-2022 Cadillac Escalade, 2015-2022 Chevrolet Suburban, 2015-2022 GMC Yukon, 2020-2022 Chevrolet Silverado 3500 HD, 2015-2022 Cadillac Escalade ESV, 2016-2019 Cadillac ATS, 2019 Chevrolet Silverado 1500 LD, 2019 GMC Sierra 1500 Limited, 2020-2022 GMC Sierra 3500 HD, 2011-2016 Buick LaCrosse, 2014-2021 Chevrolet Silverado 1500, 2018-2022 Chevrolet Express 2500, 2018-2022 Chevrolet Express 3500, 2020-2022 Chevrolet Silverado 2500 HD, 2020-2022 GMC Sierra 2500 HD, 2011-2017 Chevrolet Equinox, 2011-2022 Chevrolet Traverse, 2022 GMC Sierra 1500 Limited, 2021 GMC Sierra, 2011-2022 Buick Enclave, 2011-2019 GMC Acadia, 2014-2019 Cadillac CTS, 2015-2022 GMC Yukon XL, 2019-2020 Cadillac CT6, 2011-2017 GMC Terrain, 2014-2019 GMC Sierra, 2022 Cadillac CT4, 2014-2016 Chevrolet Impala Limited, 2014-2021 GMC Sierra 1500, 2022 Chevrolet Silverado 1500 LTD, 2017 GMC Acadia Limited, 2018-2022 GMC Savana 2500, 2018-2022 GMC Savana 3500, 2021 Chevrolet Express Pasajeros, 2012-2020 Chevrolet Impala, 2018-2021 Chevrolet Express Cargo
